Item Description Spare part number
(1) Raw panel 629775-001
646754-001
29.5-cm (11.6-in) (1366 × 768) HD BrightView LED display assembly (includes
webcam, microphone, nameplate, and logo)
NOTE: See
Display assembly subcomponents on page 19 for internal component
spare part information.
(2) Keyboard (includes keyboard cable):
●
For use in Brazil 635318-201
●
For use in French Canada 635318-121
● For use in Latin America 635318-161
●
For use in the United States 635318-001
(3) Top cover (includes ClickPad TouchPad board and cable) 635316-001
Top cover (includes ClickPad TouchPad board and cable) 636449-001
(4) Power button board 636448-001
(5) Speaker assembly 635313-001
(6) Power connector (includes power connector cable and security cable bracket) 636452-001
(7) System board:
●
E350 system board with WWAN 635314-001
● E350 system board 639297-001
(8) Webcam 635317-001
(9) RJ-45 connector (includes cable) 636452-001
(10) Fan (includes cable) 636453-001
(11) Heat sink assembly (includes replacement thermal material) 635306-001
(12) Base enclosure 635303-001
(13) RTC battery 635310-001
(14) 6-cell, 2.55-Ah (55-Wh) Li-ion battery 628419-001
(15) Hard drive (includes hard drive bracket):
● 320-GB, 7200-rpm 649908-001
●
320-GB, 5400-rpm 649908-001
●
250-GB, 7200-rpm 649904-001
Hard Drive Mounting Kit (not illustrated; includes mounting bracket and screws) 637177-001
External optical drive (not illustrated; select models only)
●
SPS-DRV DVD RW DL LS EXTERNAL 602041-001
● SPS-ADAPTER PWR USB 5V 2A 619240-001
(16) Memory module:
ENWW Computer major components 17
