8 Connector pin assignments
Audio-out (headphone)/Audio-in (microphone) jack
Pin Signal
1 Left audio signal in
2 Right audio signal in
3 Ground
4 Microphone
ENWW Audio-out (headphone)/Audio-in (microphone) jack 81
