Section V Model 3300A
Table 5-1. Required Test Equipment
Instrument Type Required Characteristics Use Recommended Instrument
Electronic Counter Range: dc to 100 kHz Performance Checks, -hp- 5245L Electronic
Accuracy: 0.1% Adjustment and Counter with 5262A Plug-
Calibration in Time Interval Unit
Distortion Analyzer Range: 10 Hz to 100kHz Performance Checks -hp- Model 331A Distortion
Freq. Accuracy: +2% Analyzer
Sensitivity: 0.3%fullscale
Input: 1 volt rms
Oscilloscope Sensitivity: 50 mV/cm Performance Checks, -hp- 175A Oscilloscope
Bandwidth: dc to 30 MHz Adjustment with -hp- Plug-in 1750B
Calibration, Repair Vertical Amplifier
Probe 10:1 Bandwidth: dc to 30 MHz Performance Checks, -hp- 10001A Probe 10:1
Division Accuracy: ±2% Adjustment and
Calibration, Repair
DC Voltmeter Accuracy: + 1% F. S. Adjustment and -hp- 3440A Digital Volt-
Range: 10 mV to 50 V Calibration, Repair meter with Plug-in -hp-
Input Impedance: 10 M
Ω
Model 3443A
Resistor 600 ohms Performance Checks -hp- Part No. 0730-0010
1/4 watt
+5%
Resistor 50 ohms Performance Checks -hp- Part No. 0683-5105
1/4 watt
+5%
Resistor 20 K Adjustment and -hp- Part No. 0686-2035
1/4 watt Calibration
+5%
Capacitor
1
µ
F 50 V
Adjustment and -hp- Part No. 0160-0859
Calibration
Variable Line Voltage Range: 100 to 130 V Performance Checks Superior Type UCIM
Transformer
DC Power Supply Range: 0 - 10 volts, 500 mA Performance Checks, -hp- 723A Power Supply
Adjustment and
Calibration
AC Voltmeter Range:10 Hz to 4 MHz Adjustment and -hp- 400F/FL Voltmeter
30 mV to 300 V Calibration
full scale
Printed Circuit
Extender Board 15 Pin Repair -hp- Part No. 5060-0049
Printed Circuit
Extender Board 22 Pin Repair -hp- Part No. 5060-0630
5-0
