PERFORMANCE CHECK TEST CARD
Hewlett-Packard Model 3300A Test Performed by ______________________________
Function Generator Date ______________________________
Serial No. __________
CHECK DESCRIPTION SPECIFICATION INDICATION
1. Dial Accuracy
1 x .01 between 90.9 and 111.1 sec _______
10 x .01 between 9.90 and 10.1 sec _______
1 x .1 between 9.09 and 11.1 sec _______
10 x .1 between 990 and 1010 ms _______
1 x 1 between 909 and 1111 ms _______
10 x 1 between 99.0 and 101.0 ms _______
1 x 10 between 90.9 and 1111 ms _______
10 x 10 between 99 Hz and 101 Hz _______
1 x 100 between 90 Hz and 110 Hz _______
10 x 100 between .99 kHz and 1.01 kHz _______
1 x 1K between .9 kHz and 1.1 kHz _______
10 x 1K between 9.9 kHz and 10.1 kHz _______
1 x 10K between 8 kHz and 12 kHz _______
10 x 10K between 98 kHz and 102 kHz _______
2. Distortion
X1K Range < 1% _______
X10K Range < 3% _______
3. Frequency Response
X.01 thru X1K Range < 1% _______
X10K Range < 3% _______
4. Maximum Output Level
No load Channel A > 35 V p-p _______
No load Channel B > 35 V p-p _______
600ê load Channel A > 16 V p-p _______
600ê load Channel B > 16 V p-p _______
50ê load Channel A > 2 V p-p _______
50ê load Channel B > 2 V p-p _______
5. Square Wave Response
a. Channel A
Rise time < 250 ns _______
Fall time < 250 ns _______
Sag < 1% _______
Overshoot < 5% _______
Symmetry < 1% _______
b. Channel B
Rise time < 250 ns _______
Fall time < 250 ns _______
Sag < 1% _______
Overshoot <5% _______
Symmetry < 1% _______
6. Sync Output
Amplitude > 10 V p-p _______
Duration
< 5µs
_______
7. Remote Frequency
Control Check vary from 10 to 100 Hz _______
8. -A Output
Channel B 180º shift _______
5-12
