Model 3300A Section VII
Table 7-1. Replaceable Parts (Cont’d)
REFERENCE -hp-
DESIGNATOR PART NO TQ DESCRIPTION MFR. MFR. PART NO.
A14R52 0757-0416 1 R: fxd prec met flm 511Ω ±1% 1/8 W 19701 MF5C T-O obd
A14R53, 0683-1025 R: fxd comp 1K ±5% 1/4 W 01121 CB1025
A14R54
A15 03300-66515 Assembly: Output Amplifier Board -hp-
A15C1* 0140-0198 C: fxd mica 200 pF ±5% 00853 RDM15F201J3C
A15C2 0121-0036 2 C: var 5.5 pF to 18 pF 72982 538-006 obd
A15C3 0180-0161 C: fxd Ta elect 3.3
Î
F ±20% 35 vdcw 05397 K3R3J35S
A15C4* 0140-01902 C: fxd mica 39 pF ±5% 04062 RDM15E390J3C
A15C5, A15C6, 0180-0161 C: fxd Ta elect 3.3
Î
F ±20% 35 vdcw 05397 K3R3J35S
A15C7
A15C8 0160-0356 5 C: fxd mica 18 pF ±5% 14655 RDM15C180J3C
A15C9* 0140-0191 2 C: fxd mica 56 pF ±5% 04062 RDM15E390J3C
A15C10 Not assigned
A15C11 0180-0376 2 C: fxd Ta elect 0.47
Î
F ±10% 35 vdcw 56289 Type 150D474X90
35A2
A15C12 0160-0356 C: fxd mica 18 pF ±5% 14655 RDM15C180J3C
A15C13* 0160-0378 2 C: fxd mica 27 pF ±5% 04062 RDM15E270J5S
A15Q1, A15Q2 1853-0010 TSTR: Si PNP** -hp-
A15Q3 1854-0005 TSTR: Si NPN 2N708 01295 2N798
A15Q4, A15Q5 1854-0039 4 TSTR: Si NPN 2N3053 86684 2N3053
A15R1 0698-3480 2 R: fxd prec met flm 3. 74K ±1% 1/2 W 75042 CEC T-O obd
A15R2 0698-3349 2 R: fxd prec met flm 5. 76K ±1% 1/2 W 75042 CEC T-O obd
A15R3* 0698-4901 2 R: fxd prec met flm 5. 36K ±1% 1/2 W 19701 MF7C T-O obd
A15R4 0698-3348 2 R: fxd prec met flm 4. 64K ±1% 1/2 W 75042 CEC T-O obd
A15R5 0757-0832 R: fxd prec met flm 4. 75K ±1% 1/2 W 75042 CEC T-O obd
A15R6 0683-4705 R: fxd comp 47Ω ±5% 1/4 W 01121 CB 4705
A15R7 2100-0361 2 R: var comp 2K ±30% 1/8 W 71450 XQS-200 obd
A15R8 0757-0041 2 R: fxd prec met flm 11. 3K ±1% 1/2 W 75042 CEC T-O obd
A15R9 0698-3352 2 R: fxd prec met flm 11. 5K ±1% 1/2 W 75042 CEC T-O obd
A15R10* 0686-2225 2 R: fxd comp 2. 2K ±5% 1/2 W 01121 EB2225
A15R11, 0698-5483 8 R: fxd prec met flm 1K 0. 5% 1/2 W 19701 MF7C T-O obd
A15R12
A15R13, 0683-2025 R: fxd comp 2K ±5% 1/4 W 01121 CB2025
A15R14
A15R15 0683-2415 2 R: fxd comp 240Ω ±5% 1/4 W 01121 CB2415
A15R16 0683-8215 2 R: fxd comp 820Ω ±5% 1/4 W 01121 CB8215
A15R17 0683-1015 4 R: fxd comp 100Ω ±5% 1/4 W 01121 CB1015
A15R18 0698-3338 2 R: fxd met oxide flm 1. 5K ±5% 2 W 07115 C425 obd
A15R19 0683-5105 2 R: fxd comp 51Ω ±5% 1/4 W 01121 CB5105
A15R20, 0698-3342 4 R: fxd prec met flm 2. 0K ±1/4% 1/2 W 75042 CEC T-O obd
A15R21
A15R22 0761-0057 2 R: fxd met oxide flm 560Ω ±5% 1 W 07115 C32 obd
A15R23 0683-2025 R: fxd comp 2K ±5% 1/4 W 01121 CB2025
A15R24, 0698-5483 R: fxd prec met flm 1K ± 0. 5% 1/2 W 19701 MF7C T-O obd
A15R25
A15R26 0683-2025 R: fxd comp 2K ±5% 1/4 W 01121 CB2025
A15R27 0683-1015 R: fxd comp 100Ω ±5% 1/4 W 01121 CB1015
A15R28 0683-2015 2 R: fxd comp 200Ω ±5%o 1/4 W 01121 CB 2015
1205-0033 Heat dissipator: semiconductor for TO-5 05820 NF-207 obd
A16 03300-66505 Output Amplifier Assembly (Components -hp-
same as A15)
7-6
