Model 3300A Section VII
Table 7-1. Replaceable Parts (Cont’d)
REFERENCE -hp-
DESIGNATOR PART NO TQ DESCRIPTION MFR. MFR. PART NO.
Miscellaneous (Cont’d)
03300-00608 1 Cover: chassis top inner shield -hp-
03300-46904 1 Cover: oven -hp-
03300-00606 1 Cover: rear panel protection plate -hp-
03300-01203 1 Clamp: holding -hp-
5000-0910 4 Clamp: panel trim -hp-
03300-04001 1 Dial: frequency -hp-
5020-0630 1 Dial: hub (for R4) -hp-
03440-48301 4 Guides: (for plug-in unit) -hp-
1205-0007 5 Heat dissipator: nut (for Q3 thru Q7) 13103 1101-24-1 (SPL)
1205-0220 5 Heat dissipator: body (for Q3 thru Q7) -hp-
1400-0084 1 Holder: fuse extractor post type for single 75915 342014
3AC cartridge fuse
5040-0619 1 Indicator: for frequency dial -hp-
0340-0039 2 Insert: teflon bushing insulator for stand- 00866 HP-3000T-1
off terminals
5040-0425 8 Insulator: BNC panel connector -hp-
0340-0140 2 Insulator: transistor (for Q1 and Q2) 86684 DF31A
1200-0080 10 Insulator: washer #10 (for Q3 thru Q7) 000LB 294834
03300-84401 1 Kit: accessory -hp-
0370-0160 1 Knob: dial round 1/58" diam black -hp-
(FREQUENCY DIAL)
0370-0025 1 Knob: round 3/4" diam black for 1/4" diam -hp-
shaft (VERNIER)
0370-0077 3 Knob: skirted bar 5/8" diam black for 1/4" -hp-
diam shaft (RANGE and FUNCTION)
0370-0133 2 Knob: skirted 5/8" diam black for 1/4" -hp-
diam shaft (AMPLITUDE)
03300-01201 1 Latch: plug-in -hp-
03300-90005 1 Manual: operating and service -hp-
2950-0039 1 Nut: hexagonal 3/8-32 by 1/2" across 28520 obd
flats by 9/16" thick brass (for mounting
R4)
03300-46902 1 Oven: assembly -hp-
5020-0900 1 Panel: trim bottom -hp-
5020-0901 1 Panel: trim top -hp-
61B-40D-4 1 Plate: frequency dial -hp-
5040-0607 1 Shaft: vernier drive disk assembly -hp-
0360-1044 4 Shorting bar: (for rear panel terminal 71785 422-13-11-013-201
strip)
1200-0168 2 Socket: transistor (for Q1 and Q2) 000LB 294834
03300-09101 1 Spring: vernier -hp-
5020-0882 1 Support: front panel -hp-
0340-0059 2 Terminal: stand-off (for C6) use with 00866 obd
0340-0039 teflon insert
0360-1327 3 Terminal strip: tie point (for Q3, Q4 71002 1355
and Q7)
2 Terminal strip: tie point (for R16 and R17) -hp-
