TM 11-6625-2495-14&P
SECTION III. TOOL AND TEST EQUIPMENT REQUIREMENTS
FOR
GENERATOR, SIGNAL G-747/U
(HP 3300A)
TOOL OR TEST MAINTENANCE TOOL
EQUIPMENT CATEGORY NOMENCLATURE NATIONAL/NATO NUMBER
REF CODE STOCK NUMBER
1 H, D Electronic Counter CP-772A/U 6625-00-973-9837
2 H, D Distortion Analyzer AN/URM-180 6625-00-089-4227
3 H, D Oscilloscope OS-261/U 6625-00-127-0079
4 H, D Probe 10:1 H.P. 10001A or equivalent
5 H, D D.C. Voltmeter AN/USM-451 6625-01-060-6804
6 H, D Resistor 600 OHM .25 watt ±5%
H.P. 0730-0010 or equivalent
7 H, D Resistor 50 drm, .25 watt ±5%
H.P. 0683-5105 or equivalent
8 H, D Resistor 20K OHM, .25 watt ±5%
H.P. 0686-2035 or equivalent
9 H, D Capacitor 1 micro f 50V. H.P. 0160-0859 or equivalent
10 H, D Variable Line Voltage Transformer CN-16/U 5950-00-235-2086
11 H, D D.C. Power Supply PP-6647/U (HP 723A) 6130-00-171-0801
12 H, D A.C. Voltmeter KE-459/U 6625-00-329-0457
13 H, D Printed Circuit Board Extender 15 Pin
H.P. 5060-0049 or equivalent
14 H, D Printed Circuit Board Extender 22 Pin
H.P. 5060-0630 or equivalent
15 H, D Tool Kit Elec Repair TK-101/G 5180-00-064-5178
16 O Tools and test equipment as authorized to the repairman
user to complete his authorized mission.
D-4
