TM 11-6625-2494-14&P

Figure 1-1. Model 3300A Function Generator

Table 1-1. Specifications

AVAILABLE PLUG-IN UNITS: SINE WAVE DISTORTION: <1%. 0.01 Hz to 10

Model 3301A Auxiliary Plug-In. kHz; <3%, 10 kHz to 100kHz on the X10K range.

Model 3302A Trigger Plug-In.

Model 3304A Sweep/Offset Plug-In. SQUARE WAVE RESPONSE: <250 nsec rise and

Model 3305A Sweep Plug-In. fall time on all ranges; <500 nsec rise and fall

time in -A; <1% sag; <5% overshoot at full out-

OUTPUT WAVEFORMS: Sinusoidal, square, and put; <1% symmetry error.

triangle selected by panel switch. (Any two

outputs available simultaneously. TRIANGLE LINEARITY: <1% 0.01 Hz to 10 kHz;

<2%, 10 kHz to 100 kHz at full output; < 1%

FREQUENCY RANGE: 0.01 Hz to 100 kHz in symmetry error.

seven decade ranges.

SYNC PULSE OUTPUT: > 10 volts peak-to-peak

FREQUENCY RESPONSE: ± 1%, 0.01 Hz to 10

open circuit, <5

sec duration. Sync pulse

kHz; ± 3%, 10 kHz to 100 kHz on the X10K occurs at crest of sine and triangle wave.

range.

DC STABILITY: Drift: <±0.25%6 of peak-to-peak

DIAL ACCURACY:. ± 1% of maximum dial setting amplitude over a period of 24 hours. (After 30

(1 minor division) 0. 01 Hz to 10 kHz; ±2% of minute warmup).

maximum dial setting (2 minor divisions) 10

kHz to 100 kHz. T. C. 0. 1%/°C. REMOTE FREQUENCY CONTROL: 0 to -10 volts

will linearly change frequency > 1 decade with-

MAXIMUM OUTPUT PER CHANNEL: > 35 volts in a single range. Frequency resetability with

peak-to-peak open circuit; > 15 volts peak-to- respect to voltage ±1% of maximum frequency

peak into 600 ohms; > 2 volts peak-to-peak into on range selected.

50 ohms.

POWER: 115 or 230 volts ±10%, 48 to 440 Hz.

OUTPUT ATTENUATORS (both channels): 40 dB Less than 50 watts.

range.

DIMENSIONS: (inches and millimeters) 5" high

OUTPUT IMPEDANCE: 600 ohms nominal (both (127 mm), 16" wide (406 mm), 11" deep

channels) ± 20%. (279 mm).

1-0
