10 Printer description ENWW
Space requirements
The printer must have the following amounts of space above and around it.
Figure 1-9 Space requirements for the HP Color LaserJet 3500 series printer
1 Height: 722 mm (28.4 in.)
2 Depth: 1480 mm (58.3 in.)
3 Width: 699.5 mm (27.6 in.)
Figure 1-10 Space requirements for the HP Color LaserJet 3700 series printer with optional Tray 3
1 Height: 862 mm (34 in.)
2 Depth: 1480 mm (58.3 in.
3 Width: 699.5 mm (27.6 in.
1
2
3
1
3
2
