pdhman.book : pdhapp.doc 32 Tue Oct 14 15:00:20 1997
32
PDH / DSn Testing With The HP 37717C
Analysis of N X 64 kb/s
3. Set up the
display as shown opposite.
In this example timeslots 3, 5, 9, 25, 26
and 27 are selected.
2M PAYLOAD selects the Framing which
must match that of the network equipment.
4. Set up the display as shown
opposite.
The RESULTS type may be changed
during the measurement without
interrupting the test.
Run the Test (N X 64 kb/s Analysis)
1. Press .
• The measurement results and alarms are available on the display
during the test period.
• The test can be halted at any time by pressing .
RECEIVE
STRUCTURED
SETTINGS
RESULTS
RUN/STOP
RESULTS
RUN/STOP
To Next Page
