PDH / DSn Testing With The HP 37717C

Analysis of N X 64 kb/s

4. Set up the display as shown

opposite.

The RESULTS type may be changed

during the measurement without

interrupting the test.

HP 37717C #2

1. Set up the

display as shown opposite.

Any settings change made on the

or displays will

automatically occur on the other.

2. Set up the display

as shown opposite.

The settings of SIGNAL rate and LINE

CODE must match those of the network

equipment.

RESULTS

OTHER

SETTINGS

CONTROL

TRANSMIT

RECEIVE

MAIN SETTINGS
