PDH / DSn Testing With The HP 37717C
BERT Testing
1. Set up the
display as shown opposite
(on both HP 37717C's if end to end).
Any settings change made on the
or displays will
automatically occur on the other.
2. Connect the HP 37717C to the line
equipment and set up the
display as shown opposite (on both HP
37717C's if end to end).
3. Select the function as
shown opposite (on both HP 37717C's if
end to end).
A LOGGING PERIOD selection of
[USER PROGRAM] [10 MIN] provides
the following:
A complete set of period and a complete
set of cumulative results logged on the
printer or disc every 10 minutes.
A complete set of cumulative results logged on the printer or to disc at the end of the
test period.
OTHER
SETTINGS
CONTROL
TRANSMIT
RECEIVE
TRANSMIT
LOGGING
