Item Component Spare part number
For use only with computer models equipped with an Intel Dual Core i5 or i3 processor
and a graphics subsystem with discrete video memory
646182-001
For use only with computer models equipped with an Intel Dual Core i5 or i3 processor
and a graphics subsystem with UMA video memory
646183-001
For use only with computer models equipped with an Intel Pentium processor and a
graphics subsystem with discrete video memory
646180-001
For use only with computer models equipped with an Intel Pentium processor and a
graphics subsystem with UMA video memory
646181-001
For use only with computer models equipped with an Intel Celeron or Core 2 processor
and a graphics subsystem with UMA video memory
646184-001
(15) Base enclosure (includes battery release latch, heat sink,
replacement thermal material, and 4 rubber feet)
646660-001
(16) Battery:
6-cell, 55-Whr, 2.55-Ah Li-ion battery 593554-001
6-cell, 47-Whr, 2.20-Ah Li-ion battery 593553-001
(17) Optical drive (select models only, includes bezel and bracket):
Blu-ray Disc ROM with SuperMulti DVD±R/RW Double-Layer Drive with LightScribe 645989-001
DVD±RW and CD-RW Super Multi Double-Layer Combo Drive with LightScribe 645988-001
(18) Hard drive (2.5-in, 7.0-mm, SATA; does not include hard drive connector cable, hard drive bracket, or screws):
For use only with Compaq 435 and Compaq 436 computer models:
250-GB, 7200-rpm 649902-001
For use with all computer models:
750-GB, 5400-rpm 634250-001
640-GB, 5400-rpm 603785-001
500-GB, 7200-rpm 634925-001
500-GB, 5400-rpm 634638-001
320-GB, 7200-rpm 641672-001 and
634862-001
320-GB, 5400-rpm 645193-001 and
622643-001
250-GB, 7200-rpm 634861-001
Hard Drive Hardware Kit (not illustrated, includes hard drive bracket and screws) 645969-001
(19) Memory modules (2, PC3, 10600, 1333-MHz):
4 GB 621569-001
2 GB 621565-001
1 GB 639738-001
24 Chapter 3 Illustrated parts catalog
