HP 430 - USB Board

USB board
Description Spare part number
USB board (includes cable) 646128-001
Before removing the USB board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 43), and then remove the following components:
●
Memory module/wireless module compartment cover (see
WLAN module on page 44)
●
Hard drive (see
Hard drive on page 48)
●
Keyboard (see
Keyboard on page 53)
●
Top cover (see
Top cover on page 56)
●
Speakers (see
Speakers on page 63)
Remove the USB board:
▲
Remove the USB board and cable.
