Vertical
Input
Impedance
Softkey
Input
Impedance
Softkey
The
input
impedance
softkey
allows
you
to
select
the
input
coupling
impedance.
The
choices
are
1
MQ
for
ac
coupling
and
selectable
1
MQ
or
50
Q
de
when
dc
coupling
is
selected
in
the
coupling
function.
When
50
Q
is
selected,
the
50
Q
indicator
LED
on
the
front
panel
is
lit
for
that
channel.
More
Preset
Probe
Softkey
VERTICAL
MORE
The
more
preset
probe
softkey
gives
you
access
to
a
second-level
423
4
|
channel
menu.
more
