HP 556dn

Printer fully closed Printer fully opened
3. Width 530 mm (20.8 in) 1038 mm (40.8 in)
Weight 34.1 kg (75.2 lb)
Figure 1-3 Dimensions for Tray 3
2
1
2
3
3
1
1. Height 138 mm (5.4 in)
2. Depth Tray closed: 396 mm (15.5 in)
Tray opened: 678 mm (26.6 in)
3. Width Lower-left door closed: 514 mm (20.2 in)
Lower-left door opened: 1038 mm (40.8 in)
Weight 5.4 kg (11.8 lb)
Figure 1-4 Dimensions for the printer stand
2
3
1
2
1
3
1. Height 640 mm (25.1 in)
2. Depth Tray closed: 669 mm (26.3 in)
Tray opened: 810 mm (31.8 in)
12 Chapter 1 Printer overview ENWW
