HP X122 1G SFP LC BX-U
Transceiver
(J9143B)
A small form-factor
pluggable (SFP) Gigabit-BX
(bi-directional) "upstream"
transceiver that provides a
full-duplex Gigabit solution
up to 10 km on one strand
of single-mode fiber. The
J9143B connects to the
J9142B "downstream"
transceiver, or to any IEEE-
standard 1000BASE-BX10-
D ("downstream")
device.
Ports
1 LC 1000BASE-BX10 port (IEEE 802.3ah Type 1000BASE-BX10-U); Duplex:
full only
Physical characteristics
Dimensions
2.19(d) x 0.54(w) x 0.46(h) in. (5.57 x 1.37 x 1.18
cm)
Weight
0.04 lb. (0.02 kg)
Environment
Operating temperature
32ºF to 158ºF (0ºC to 70ºC)
Operating relative
humidity
0% to 95%, non-condensing
Non-operating/
Storage temperature
–40ºF to 185ºF –40ºC to 85ºC)
Cabling
Type:
Single-mode fiber optic, complying with ITU-T G.652;
Maximum distance:
0.5-10,000 m (single-mode fiber)
Notes
Transmit wavelength: 1310 nm. Receive wavelength: 1490 nm.
For supported platforms and minimum software requirements to support this
product, see the document titled "Support for the HP BX Transceivers" on the
"HP Mini-GBICs and SFPs" Manuals Web page.
The J9143B connects to the J9142B "downstream" transceiver, or to any IEEE-
standard 1000BASE-BX10-D ("downstream") device. (A 1000-BX-U
transceiver can only connect to a 1000-BX-D product. You cannot connect two
1000-BX-U transceivers together.)
Power consumption is 1 watt maximum.
Services
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 0.5 m Multimode OM3
LC/LC Optical Cable
(AJ833A)
Cabling
Cable type
:
50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective
modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of
up to 300 m
Maximum distance
:
10Gbps Transfer Rate (Ethernet): 300m
Notes
Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um
fiber optic cable and Ethernet assembly with LC duplex connectors on one end
and LC duplex connectors on other end.
Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um
Coating diameter: 245 ± 10um
Optical glass: Bandwidth: For LED sources: 1500/500 MHz-km
@850/1300nm.
Optical glass: Bandwidth: For Laser sources: 2000/500 MHz-km
@850/1300nm. VCSEL Laser sources: 600 / 600 meters @850/1300nm
for Gigabit Ethernet compliant links.
CABLE: The cable is duplex zipcord graded index 50/125um multimode
QuickSpecs
HP 6200 yl Switch Series
Accessory Product Details
DA - 12437 North America — Version 17 — December 9, 2013
Page 29
