optical fiber and designed to work in both the 850 and 1300 nm
wavelength windows.
BULK CABLE & CABLE ASSEMBLY CONFIGURATION:
Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.
Jacket Color: Aqua for OM3 multimode per TIA 598
Boot Color: White
Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M
added for lengths > 30 meters.
Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310
nm @ 23°C as tested in accordance with EIA 455-46.
Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP Premier Flex LC/LC
Multi-mode OM4 2 fiber
1m Cable (QK732A)
Notes
Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um
duplex cable and Ethernet assembly with LC duplex connectors on each end.
• Core Diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating
diameter: 245 ± 10um
• Bandwidth: 3000 MHz-km @ 850nm (Laser)
• Jacket Color: Blue
• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH) thermoplastic
• Boot Color: White
• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um, Type
OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white
stripe that runs the entire length of the cable.
• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m added
for lengths >30m
• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm @
23°C as tested in accordance with EIA 455-45
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 6200 yl Switch Series
Accessory Product Details
DA - 12437 North America — Version 17 — December 9, 2013
Page 30
