12. Keyboard (see Keyboard on page 47).

13. Hinge covers (see Hinge cover on page 53).

14. Base enclosure (see Base enclosure on page 55).

15. System board (see System board on page 57).

16. Fan/heat sink assembly (see Fan and heat sink assembly on page 59).

17. Top cover (see Top cover and TouchPad on page 63).

Remove the display assembly:

1. Position the computer upright, with the front toward you.

2. Open the computer.

3. Remove 2 screws from each hinge (1) and then remove the display (2):

Remove the display assembly components:

1. If it is necessary to replace the display bezel:

a. Close the computer, position it so you can access the bottom of the display, and then open the

computer slightly.

Display assembly 81

Questions and Answers:

Need help?

Do you have a question about the HP 645 G3 and is the answer not in the manual?

HP 645 G3 Specifications

General

Operating System	Windows 10 Pro
Processor	AMD PRO A10-8730B
Display	14-inch diagonal HD SVA anti-glare (1366 x 768)
Weight	Starting at 1.9 kg
Battery	3-cell, 48 Wh Li-ion
Ports	HDMI, VGA, Ethernet, headphone/microphone combo jack
Wireless	Bluetooth 4.2
Storage	Up to 512 GB SATA SSD or 1 TB HDD
Graphics	Integrated AMD Radeon R5 Graphics
