HP 645 G3 User Manual

b. Flex the inside edges of the top edge (1), the left and right sides (2), and the bottom edge (3) of
the display bezel until the bezel disengages from the display enclosure.
2. If it is necessary to replace the display panel:
a. Remove the four M2x3L P1 screws that secure the display panel to the display enclosure.
●
781959-001—35.6-cm (14.0-in), LED, AntiGlare display panel, UWVA
●
784476-001—35.6-cm (14.0-in), LED, AntiGlare display panel, SVA HD+
82 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts

HP 645 G3 Specifications

General

Operating System	Windows 10 Pro
Processor	AMD PRO A10-8730B
Display	14-inch diagonal HD SVA anti-glare (1366 x 768)
Weight	Starting at 1.9 kg
Battery	3-cell, 48 Wh Li-ion
Ports	HDMI, VGA, Ethernet, headphone/microphone combo jack
Wireless	Bluetooth 4.2
Storage	Up to 512 GB SATA SSD or 1 TB HDD
Graphics	Integrated AMD Radeon R5 Graphics
