Ethernet network examples
These are some common Ethernet network configurations:
Shared Internet connection with a router
acting as a gateway
In this example, a router manages the network connections
and acts as a
gateway between the network and the
Internet.
Shared internet connection with a PC acting as
a gateway
In this example, the network devices are connected to a hub.
A computer on the network acts as the
gateway between the
network and the Internet. The gateway computer uses
Windows Internet Connection Sharing (ICS) to manage the
network connections and provide Internet access to the other
devices.
