7 Screw listing
This section provides specification and reference information for the screws and screw locks used in
the computer. All screws and screw locks listed in this section are available in the Screw Kit, spare part
number 443906-001.
Torx T8M2.5×7.0 screw
Color Quantity Length Thread Head diameter
Black 2 7.0 mm 2.5 mm 5.0 mm
Where used: 2 screws that secure the bottom edge of the display bezel to the display assembly
Torx T8M2.5×7.0 screw 115
