3. Remove the two HM5.0×9.0 screw locks (2) that secure the top cover to the computer.
4. Turn the computer right-side up, with the front toward you.
5. Disconnect the TouchPad cable (1) from the system board.
NOTE: Step 6 applies only to HP Compaq 6715b and 6710b computer models.
6. Disconnect the fingerprint reader board cable (2) from the system board.
7. Remove the microphone (3) from the clip built into the top cover and remove the microphone cable
from the clips built into the top cover.
82 Chapter 4 Removal and replacement procedures

HP 6710b - Compaq Business Notebook Specifications

General

Processor	Intel Core 2 Duo
Display	15.4-inch
RAM	Up to 4 GB DDR2
Battery	6-cell Lithium-Ion
Wireless	802.11a/b/g
Graphics	Intel GMA X3100
Optical Drive	DVD+/-RW
Operating System	Windows Vista Business
Weight	2.7 kg
Chipset	Mobile Intel GM965 Express
Network	10/100/1000 Gigabit Ethernet
Ports	RJ-45
Display Resolution	1280x800 (WXGA)
Storage	80/120/160 GB
