INTEL® STANDARD MANAGEABILITY
Includes DASH 1.0/1.1 compliance plus:
System Defense
Agent Presence
SOL/IDE Redirection
CISCO NAC/SDN support
ME Wake on LAN
Host Based Configuration
ME Firmware Rollback
IPv6 Support
DASH 1.0/1.1 compliance:
Boot Control
HW Inventory
SW Inventory
Power State Management
HW Alerting
SMBIOS
System Management BIOS, previously known as DMI BIOS, is used to store system management information
GRAPHICS
Integrated (depends on processor)
Intel HD Graphics: Basic, 2000, 2500, or 4000
Models with Intel Core i3/i5/i7 processors include HD 2000, 2500, or 4000 graphics. Models with Pentium or Celeron processors
include HD graphics. Please see specific processors for graphics configuration.
Discrete (optional)
AMD Radeon HD 7650A 2GB DDR3 MXM Graphics
Graphics controller AMD Radeon HD 7650A
Core clock 600MHz max
Memory clock 800MHz max
Memory frame buffer 2GB, DDR3, 128-bit wide
Memory 2GB DDR3
Supported Graphics APIs DX11, OpenGL, full 1080p Blu-Ray Disc
(H264) playback in hardware, Multi-
Stream DisplayPort support (supports up
to 4 displays total - 4 independent video
and audio streams)
NVIDIA GeForce GT 630M 2GB DDR3 MXM Graphics
Graphics controller NVIDIA GF108
Core clock 675MHz
QuickSpecs
HP Compaq 8300 Elite All-in-One PC
Standard Features
DA - 14352 Worldwide — Version 38 — November 21, 2013 Page 9

HP 8300 Specifications

General

Processor Speed	3.2 GHz
Chipset	Intel Q77 Express
Graphics	Intel HD Graphics 2500
Optical Drive	DVD-ROM
Audio	Integrated
Network	Gigabit Ethernet
Ports	VGA, DisplayPort, Serial, PS/2
Operating System	Windows 7 Professional
Form Factor	Small Form Factor
USB Ports	USB 2.0 and USB 3.0 ports
