HP 8590 L-Series User Manual

PWR SWP
ON OFF
Attenuator
Power Sweer
Range
-1 to -10
-10.1 to -18
-18.1 to -26
-26.1 to -34
-34.1 to -42
-42.1 to -50
-50.1 to -58
-58.1 to -66
HP 85901, and HP 8591 E with Option 010 or 011. HP 85933, HP 85944
HP 85954 and HP 8596E with 0ption 010.
activates (ON) or deactivates (OFF) the power-sweep function, which sweeps
the output power of the tracking generator over the selected power-sweep
range. The value of the power-sweep range is displayed in the active-function
block when PWR SWP ON OFF is turned on. The available power-sweep
range is a function of the source attenuator setting: For power sweeps, press
SRC ATN MAN AUTO until (MAN) is underlined so the spectrum analyzer source
attenuator is manually set (decoupled). For a given source attenuation setting,
the maximum specified power-sweep range is given by the following:
mwer Sweep Range for the HP 859OL and HP 8591 E is (- 15 dBm minus
the source attenuation setting) to (0 dBM minus the source attenuation
setting). For example, if the source attenuation setting is 20 dB, the maximum
power sweep range is from -35 dBm (-15 dBm - 20 dB) to -20 dBm
(0 dBm - 20 dB). The starting power level is the source power setting. The
ending power level is the sum of the source power setting plus the source
power sweep setting. Source power sweep may be set as high as 20 dB, but
performance is specified only up to 15 dB.
Ebwer Sweep Range for the HP 8593E, HP 8594E, HP 85953, and HP 85963 is
also related to the source attenuation setting. See Table 7-13.
‘able 7-13. HP 85933, HP 85943, HP 85953, and HP 85963
The output power of the tracking generator is swept according to the sweep
rate of the spectrum analyzer. The output power is always swept from the
source power setting to a higher power setting (negative source power sweep
values are not allowed). Refer to the calibration guide for your instrument for
more information regarding source power and source attenuation relationships.
Power-sweep measurements are particularly useful in making gain compression
measurements or output power versus frequency measurements.
Front-Panel Key Access: [AUX]
Key Descriptions 7-71

HP 8590 L-Series Specifications

General

Input Impedance	50 ohms
Video Bandwidth (VBW)	1 Hz to 3 MHz
Amplitude Accuracy	±1.5 dB
Maximum Input Level	+30 dBm
Power Requirements	100-240 VAC, 50/60 Hz
Input VSWR	1.5:1 (typical)
