Installation Note 08714-90054 3

Description

This document details a special procedure for installing the CPU board in the HP 8712ET/ES

and HP 8714ET/ES RF network analyzers. This special procedure is necessary if the existing

CPU BootROM IC is version E.01.00, or HP part number 08714-80012.

Parts List

NOTE The manuals mentioned in this document can be accessed on the internet by

searching for the part number of the manual at the following Web site:

http://www.agilent.com

For example, to access the Service Guide, go to the Web site and search for

“08714-90017”.

Products Affected:......................... HP8712ET/ES and HP 8714ET/ES RF Network

Analyzers

Serial Numbers:........................... All

To Be Performed By: . . . . . . . . . . . . . . . . . . . . . . (X ) HP Service Center

(X ) Customer or Personnel Qualiﬁed by HP

(X ) HP Personnel On-site

Estimated Installation Time:................ 30 minutes

Quantity Description HP Part Number

1 A2 CPU Board (new)

— or —

A2 CPU Board (rebuilt-exchange)

08714-60175

08714-69175

1 BootROM IC (U335) 08714-80013

1 IC Extraction Tool

(not used in this special procedure)

—
