Introduction
1–14
SCSI
Bus T
ermination Guidelines
There are certain guidelines to follow when terminating a SCSI bus.
CAUTION: Unless the SCSI bus is properly terminated, the bus will not
operate. Terminators provide impedance matching on SCSI bus
signal lines.
• The last device connected to the SCSI bus must be terminated with a SCSI
terminator. Use a Hewlett-Packard K2291 50-pin low-density bail-lock active
terminator or a Hewlett-Packard C2904A high-density thumbscrew active
terminator to terminate the last SCSI option device.
• Any termination on other devices on the bus must be removed. This includes
external termination plugged into a SCSI receptacle on the device, or internal
resistor packs. (Refer to peripheral device or system configuration manuals for
termination information.)
