The HP Rack 10000 Series were designed to the19-inch RETMA standard. The Racks accommodate all HP
equipment (ProLiant, Alpha Systems, StorageWorks, UPS, and PDUs) in addition to select third-party equipment.
See HP Rack 10000 G2 Series QuickSpecs
HP Rack 10000 G2 Series QuickSpecsHP Rack 10000 G2 Series QuickSpecs
HP Rack 10000 G2 Series QuickSpecs for details:
http://h18000.www1.hp.com/products/quickspecs/12402_div/12402_div.HTML
Configuration Guidelines
Configuration GuidelinesConfiguration Guidelines
Configuration Guidelines
All DS/ES Base Systems require a rack kit to mount systems in a 10000 G2 Series Rack (see below).
All Base Systems include all required internal IEC/IEC power cords.
10000 G2 Series Rack
10000 G2 Series Rack10000 G2 Series Rack
10000 G2 Series Rack 10000 G2 Series 42U Rack - mandatory selection of three-phase or two single-phase
Power Distribution Units required
AF004A
Rack Kit – Mandatory
Rack Kit – MandatoryRack Kit – Mandatory
Rack Kit – Mandatory
for 10000 G2 Series Rack
Order one for each DS25 System for mounting in 10000 G2 Series Rack 3X-BA57R-RC
Side Panel Kit –
Side Panel Kit –Side Panel Kit –
Side Panel Kit –
Mandatory
MandatoryMandatory
Mandatory
Choice of Side Panel Kit or
Baying Kit for 10000 G2
Series Rack
Order one per 10000 G2 Series Rack AF054A
Baying Kit – Mandatory
Baying Kit – MandatoryBaying Kit – Mandatory
Baying Kit – Mandatory
Choice of Side Panel Kit or
Baying Kit for 10000 G2
Series Rack
Used to join two or more Series 10000 G2 Racks 248931-B21
Power Distribution Units
Power Distribution Units Power Distribution Units
Power Distribution Units –
––
– Mandatory for 10000 G2 Series Rack
Mandatory for 10000 G2 Series Rack Mandatory for 10000 G2 Series Rack
Mandatory for 10000 G2 Series Rack
Single-phase PDU
Single-phase PDUSingle-phase PDU
Single-phase PDU Single-phase PDU for North America/Japan
200-240V 20A input plug NEMA L620P; 16 outlets
3X-H7609-EB
Single-phase PDU for International,
240V 20A input plug IEC309, 16 outlets
3X-H7609-DB
Shelves Supported in
Shelves Supported inShelves Supported in
Shelves Supported in
Series 10000 Racks
Series 10000 RacksSeries 10000 Racks
Series 10000 Racks
– Optional
– Optional– Optional
– Optional
StorageWorks Model 4314R Ultra3 SCSI (LVD) single-bus Universal drive rackmount
shelf, includes one power supply, U.S./International
DS-SL13R-AA
StorageWorks Model 4314R Ultra3 SCSI (LVD) single-bus Universal drive rackmount
shelf, includes one power supply, Japan
DS-SL13R-AJ
StorageWorks Model 4354R Ultra3 SCSI (LVD) split-bus Universal drive rackmount
shelf, includes two redundant power supplies, U.S./International
DS-SL13R-BA
StorageWorks Model 4354R Ultra3 SCSI (LVD) split-bus Universal drive rackmount
shelf, includes two redundant power supplies, Japan
DS-SL13R-BJ
StorageWorks Modular Smart Array SW4414R Single Bus Ultra320 rackmountable
SCSI disk drive, 4-node Storage Enclosure (302969-B21). Includes one 12-foot
VHDCI/VHDCI SCSI cable and two IEC-C13 power cords. See Supported Options List
for configuration details --
http://h18002.www1.hp.com/alphaserver/options/ases45/ases45_options.html
3R-A4075-AA
StorageWorks Modular Smart Array SW4454R Dual Bus Ultra320 rackmountable
SCSI disk drive, 4-node Storage Enclosure (302970-B21). Includes two 12-foot
VHDCI/VHDCI SCSI cables and two IEC-C13 power cords. See Supported Options
List for configuration details --
http://h18002.www1.hp.com/alphaserver/options/ases45/ases45_options.html
3R-A4076-AA
