7
Figure 2: Direction of Wiping for the HP51645A, the HPC6104A, the
HP51641A, the HPC6105A, the HPC1823A, the HPC6116A, the
HPC6168A, the HPC6169A, and the HPC6170A.
The direction of the wipe should especially be monitored on the tri-color pens
such as the HP51641A, the HPC6105A, the HPC1823A, and the HPC6116A.
The cartridge can be ruined due to color mixing if the top plate is not wiped in the
direction of the nozzle rows.
The following cartridges should be wiped against the row of nozzles to perform
optimally (see Figure 3 & 4):
? HP51626A, HP51638A
? HP51633M, HPC6117A
Figure 3: Direction of Wiping for the HP51626A, HP51638A, the
HP51633M, and the HPC6117A
? HP51640(A,C,M,Y)
