c. Disconnect the webcam/microphone module cable (2) from the webcam/microphone module.
d. Remove the webcam/microphone module.
The webcam/microphone module is available using spare part number L07235-001.
10. If it is necessary to replace the display panel:
a. Remove the display bezel.
b. Remove the six Phillips PM2.0×2.8 screws (1) that secure the display panel and display panel bracket
to the display back cover.
c. Remove the display panel bracket (2).
NOTE: The display panel bracket is available using spare part number .
Component replacement procedures 37
