Speakers
Description Spare part number
Speaker Kit (includes cables) 859528-001
Before removing the speakers, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the two computer feet and base enclosure (see Computer feet and base enclosure on page 19).
5. Remove the battery (see Battery on page 21).
6. Remove the heat sink (see Heat sink on page 21).
7. Remove the WLAN module (see WLAN module on page 23).
8. Remove the system board (see System board on page 25).
Remove the speakers:
1. Disconnect the speaker cables (1).
2. Remove the speakers (2).
Reverse this procedure to install the speakers.
Component replacement procedures 27
