5 Removal and replacement procedures
CAUTION: Components described in this chapter should only be accessed by an authorized service provider.
Accessing these parts can damage the computer or void the warranty.
NOTE: HP continually improves and changes product parts. For complete and current information on
supported parts this your computer, go to http://partsurfer.hp.com, select your country or region, and then
follow the on-screen instructions.
Component replacement procedures
There are as many as 54 screws that must be removed, replaced, and/or loosened when servicing
the computer. Make special note of each screw size and location during removal and replacement.
Computer feet and base enclosure
Description Spare part number
Computer feet (included in the rubber kit) 861673–001
Base enclosure 859526–001
Before replacing the computer feet and base enclosure, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer .
Remove the computer feet:
1. Close the computer and position it upside down, with the front toward you.
2. Insert a tool (1) with no sharp edges between the base enclosure and one end of the rubber feet.
3. Pull up the rubber feet (2) lightly and quickly.
Component replacement procedures 19
