Keyboard/top cover
NOTE: The keyboard/top cover spare part kit does not include the TouchPad or the TouchPad cable. The
TouchPad spare part number 861674-001.
Description Spare part number Description Spare part number
For use in Belgium 859535-A41 For use in the Netherlands 859535-B31
For use in Canada 859535-DB1 For use in Russia 859535-251
For use in the Czech Republic
and Slovenia
859535-FL1 For use in Saudi Arabia 859535-171
For use in Denmark, Finland,
and Norway
859535-DH1 For use in Spain 859535-071
For use in France 859535-051 For use in Switzerland 859535-BG1
For use in Germany 859535-041 For use in Taiwan 859535-AB1
For use in Israel 859535-BB1 For use in Thailand 859535-281
For use in Italy 859535-061 For use in the United Kingdom 859535-031
For use in Japan 859535-291 For use in the United States 859535-001
Before removing the keyboard/top cover, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the two computer feet and base enclosure (see Computer feet and base enclosure on page 19).
5. Remove the battery (see Battery on page 21).
6. Remove the heat sink (see Heat sink on page 21).
7. Remove the WLAN module (see WLAN module on page 23).
8. Remove the system board (see System board on page 25).
9. Remove the speakers (see Speakers on page 27).
10. Remove the SD card reader board SD card reader board on page 28.
11. Remove the TouchPad board (see TouchPad board on page 29).
12. Remove the display assembly (see Display assembly on page 31).
Remove the keyboard/top cover.
Reverse these procedures to install the keyboard/top cover.
30 Chapter 5 Removal and replacement procedures
