HP Chromebook 14 G6 Service Manual

5 Removal and replacement procedures
IMPORTANT: Components described in this chapter should be accessed only by an authorized service provider.
Accessing these parts can damage the computer or void the warranty.
NOTE: HP continually improves and changes product parts. For complete and current information about
supported parts for this computer, go to http://partsurfer.hp.com, select your country or region, and then follow
the on-screen instructions.
Component replacement procedures
There are as many as 49 screws that must be removed, replaced, or loosened when servicing the computer.
Make special note of each screw size and location during removal and replacement.
Keyboard/top cover
Table 5-1 Keyboard/top cover spare part information
For use in country
or region
Spare part number For use in country
or region
Spare part number For use in country
or region
Spare part number
Keyboard/top cover with backlight
(includes backlight cable and
keyboard cable):
For use in Israel L90460-BB1 For use in South Korea L90460-AD1
For use in Belgium L90460-A41 For use in Italy L90460-061 For use in Spain L90460-071
For use in Brazil L90460-201 For use in
Latin America
L90460-161 For use in Switzerland L90460-BG1
For use in Canada L90460-DB1 For use in
the Netherlands
L90460-B31 For use in Taiwan L90460-AB1
For use in the Czech
Republic and
Slovakia
L90460-FL1 For use in Portugal L90460-131 For use in Thailand L90460-281
For use in Denmark,
Finland, and Norway
L90460-DH1 For use in Romania L90460-271 For use in Turkey L90460-141
For use in France L90460-051 For use in Russia L90460-251 For use in
the United Kingdom
L90460-031
For use in Germany L90460-041 For use in Saudi Arabia L90460-171 For use in
the United States
L90460-001
Keyboard/top cover without backlight
(includes keyboard cable):
For use in Israel L90459-BB1 For use in South Korea L90459-AD1
For use in Belgium L90459-A41 For use in Italy L90459-061 For use in Spain L90459-071
For use in Brazil L90459-201 For use in
Latin America
L90459-161 For use in Switzerland L90459-BG1
For use in Canada L90459-DB1 For use in
the Netherlands
L90459-B31 For use in Taiwan L90459-AB1
20 Chapter 5 Removal and replacement procedures

HP Chromebook 14 G6 Specifications

General

Form factor	Clamshell
Product type	Chromebook
Product color	Black
Country of origin	China
Intel® vPro™ Platform Eligibility	No
LED backlight	Yes
RGB color space	NTSC
Display diagonal	14 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	250 cd/m²
Native aspect ratio	16:9
NTSC coverage (typical)	45 %
Display bezel technology	Micro-Edge
Display diagonal (metric)	35.6 cm
Memory slots	1x SO-DIMM
Internal memory	8 GB
Memory clock speed	3733 MHz
Memory form factor	SO-DIMM
Internal memory type	LPDDR4-SDRAM
Maximum internal memory	- GB
Storage media	eMMC
Total storage capacity	64 GB
Compatible memory cards	SD, SDHC, SDXC
Number of built-in speakers	2
MIMO type	Multi User MIMO
Antenna type	2x2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN controller model	Intel Dual Band Wireless-AC 9560
WLAN controller manufacturer	Intel
Front camera HD type	HD
Front camera signal format	720p
HDMI version	1.4b
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
Pointing device	Touchpad
Keyboard special features	Protection against removal of keys and liquid ingress
Operating system installed	ChromeOS
AC adapter power	45 W
Battery capacity	47 Wh
HP segment	Business
HP speaker type	HP Dual Speakers
Tjunction	105 °C
Processor cache	4 MB
Processor cores	4
System bus rate	- GT/s
Processor family	Intel® Celeron®
Processor socket	BGA 1090
Processor codename	Gemini Lake Refresh
Processor frequency	1.1 GHz
Processor cache type	L3
Processor lithography	14 nm
PCI Express slots version	2.0
Processor boost frequency	2.6 GHz
Processor operating modes	64-bit
PCI Express configurations	1x4+1x2, 4x1, 2x1+1x2+1x2
Thermal Design Power (TDP)	6 W
Maximum number of PCI Express lanes	6
Number of execution units	12
On-board graphics card ID	0x3185
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics 600
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	200 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	700 MHz
Sustainability certificates	ENERGY STAR
Processor ARK ID	197309
Processor package size	25 x 24 mm
Supported instruction sets	SSE4.2

Weight and Dimensions

Depth	227 mm
Width	326.5 mm
Height	18.3 mm
Weight	1540 g
