HP Chromebook 14 G6 Service Manual

1 Product description
Table 1-1 Product description
Category Description
Product Name HP Chromebook™ 14 G6
Processor ● Intel® Celeron™ N4120 1.1 GHz (SC turbo up to 2.6 GHz) quad core processor (4.0 MB L2 cache,
2400 MHz FSB, 6 W)
● Intel Celeron N4100 1.1 GHz (SC turbo up to 2.6 GHz) quad core processor (4.0 MB L2 cache,
2400 MHz FSB, 6 W)
● Intel Celeron N4020 1.1 GHz (SC turbo up to 2.8 GHz) dual core processor (4.0 MB L2 cache,
2400 MHz FSB, 6 W)
● Intel Celeron N4000 1.1 GHz (SC turbo up to 2.6 GHz) dual core processor (4.0 MB L2 cache,
2400 MHz FSB, 6 W)
Chipset Intel integrated with processor
Panel ● 14.0 in, full high-denition (FHD) (1920×1080), antiglare, white light emitting diode (WLED),
UWVA, liquid crystal display (LCD), eDP, slim touchscreen display with narrow bezel and privacy
shutter; typical brightness: 250 nits
● 14.0 in, FHD (1920×1080), antiglare, WLED, UWVA, LCD, eDP, slim touchscreen display with
narrow bezel; typical brightness: 250 nits
● 14.0 in, FHD (1920×1080), antiglare, WLED, UWVA, LCD, eDP, slim non-touchscreen display with
narrow bezel and privacy shutter; typical brightness: 250 nits
● 14.0 in, FHD (1920×1080), antiglare, WLED, UWVA, LCD, eDP, slim non-touchscreen display with
narrow bezel; typical brightness: 250 nits
● 14.0 in, high-denition (HD) (1366×768), brightview, WLED, SVA, LCD, slim touchscreen display
with narrow bezel and privacy shutter; typical brightness: 220 nits
● 14.0 in, HD (1366×768), brightview, WLED, SVA, LCD, slim touchscreen display with narrow
bezel; typical brightness: 220 nits
● 14.0 in, HD (1366×768), antiglare, WLED, SVA, LCD, slim non-touchscreen display with narrow
bezel and privacy shutter; typical brightness: 220 nits
● 14.0 in, HD (1366×768), antiglare, WLED, SVA, LCD, slim non-touchscreen display with narrow
bezel; typical brightness: 220 nits
Memory Support for the following:
LPDDR4-4266, 0.6 V,nonupgradeable, on-board system memory in 16-GB conguration
LPDDR4-3733, 1.1 V,nonupgradeable, on-board system memory in 16-GB and 8-GB congurations
Storage Embedded Multimedia Controller (eMMC): Supports MO-276 MMC v 5.0 in 128 GB, 64 GB, 32 GB, and
16 GB congurations
Solid-state drive: Supports a 256 GB PCIE, NVME, value solid-state drive and a 128 GB M2, SATA-3,
solid-state drive with triple level cell (TLC)
Audio and video Fixed (no tilt), 720p HD camera with integrated into display assembly
Dual-array microphones with appropriate echo-cancellation, noise-suppression software
Dual speakers
1

HP Chromebook 14 G6 Specifications

General

Form factor	Clamshell
Product type	Chromebook
Product color	Black
Country of origin	China
Intel® vPro™ Platform Eligibility	No
LED backlight	Yes
RGB color space	NTSC
Display diagonal	14 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	250 cd/m²
Native aspect ratio	16:9
NTSC coverage (typical)	45 %
Display bezel technology	Micro-Edge
Display diagonal (metric)	35.6 cm
Memory slots	1x SO-DIMM
Internal memory	8 GB
Memory clock speed	3733 MHz
Memory form factor	SO-DIMM
Internal memory type	LPDDR4-SDRAM
Maximum internal memory	- GB
Storage media	eMMC
Total storage capacity	64 GB
Compatible memory cards	SD, SDHC, SDXC
Number of built-in speakers	2
MIMO type	Multi User MIMO
Antenna type	2x2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN controller model	Intel Dual Band Wireless-AC 9560
WLAN controller manufacturer	Intel
Front camera HD type	HD
Front camera signal format	720p
HDMI version	1.4b
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
Pointing device	Touchpad
Keyboard special features	Protection against removal of keys and liquid ingress
Operating system installed	ChromeOS
AC adapter power	45 W
Battery capacity	47 Wh
HP segment	Business
HP speaker type	HP Dual Speakers
Tjunction	105 °C
Processor cache	4 MB
Processor cores	4
System bus rate	- GT/s
Processor family	Intel® Celeron®
Processor socket	BGA 1090
Processor codename	Gemini Lake Refresh
Processor frequency	1.1 GHz
Processor cache type	L3
Processor lithography	14 nm
PCI Express slots version	2.0
Processor boost frequency	2.6 GHz
Processor operating modes	64-bit
PCI Express configurations	1x4+1x2, 4x1, 2x1+1x2+1x2
Thermal Design Power (TDP)	6 W
Maximum number of PCI Express lanes	6
Number of execution units	12
On-board graphics card ID	0x3185
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics 600
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	200 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	700 MHz
Sustainability certificates	ENERGY STAR
Processor ARK ID	197309
Processor package size	25 x 24 mm
Supported instruction sets	SSE4.2

Weight and Dimensions

Depth	227 mm
Width	326.5 mm
Height	18.3 mm
Weight	1540 g
