Separation assembly removal and replacement
Use the following procedure to remove the separation assembly.
1. Remove Tray 2 (shown) or optional Tray 3.
2. Remove two screws that attach the separation assembly.
3. Remove the separation assembly.
To replace the separation assembly, follow steps 1 through 3 above in reverse order.
NOTE Align the tabs with the two slots and then replace the separation assembly.
ENWW Removal and replacement procedures 95
