HP CM1015 - Color Laserjet All

Figure 1-2 Back and side view
1 On/off switch
2 Power connection
3 Jam access door
4 Dust cover
5 DIMM access door
6 Network connection to 10/100 Base-T network (HP Color LaserJet CM1017 MFP only)
7 USB connection
Figure 1-3 Transfer belt view (HP Color LaserJet CM1015 MFP)
1 Transfer belt (ETB)
6 Chapter 1 Product information ENWW
