Table 7-8 External panels and covers
Ref Description Part number Qty
PANEL FRONT (TRAY 2 FRONT COVER) RC1–5346–000CN
RIGHT FRONT PHOTO MEMORY COVER CB395–67910
1 COVER, FACE-DOWN RC2-1672-000CN 2
2 COVER, FACE-UP, REAR RC2-1675-000CN 1
3 COVER, LEFT RC1-5183-000CN 1
4 COVER, CASSETTE, LEFT RC2-1691-000CN 1
5 COVER, CASSETTE RIGHT RC2-1692-000CN 1
6 ARM, FRONT DOOR, LEFT RC1-5192-000CN 1
7 ARM, FRONT DOOR, RIGHT RM1-5193-000CN 1
8 SHAFT, FRONT DOOR ARM RC1-5194-000CN 2
9 COVER, CASSETTE DUST RC1-5200-000CN 1
10 PLATE, REAR RC2-1687-000CN 1
11 FRONT DOOR ASSEMBLY RM1-4314-000CN 1
12 LID, CONTROLLER RC1-5229-000CN 1
13 RIGHT COVER ASSEMBLY RM1-1858-000CN 1
14 ROLLER, FACE-UP RC2-1682-000CN 4
15 TRAY, FACE-UP RC2-1671-000CN 1
16 SCREW, TAPPING, TRUSS HEAD M4x10 XB4-7401-005CN 3
17 SCREW RS, M3x8 XA9-1500-000CN 10
18 COVER, CONTROLLER RC1-5228-000CN 1
19 SHEET, LEFT PANEL, LOWER RC1-5204-000CN 1
20 LEVER, LINK RC1-5272-000CN 2
21 UPPER COVER ASSEMBLY RM1-4311-000CN 1
ENWW Assembly locations 169
