Part number Description Table and page
RC1-5147-000CN COVER, CABLE, UNIT Internal components (1 of 3)
on page 173
RC1-5183-000CN COVER, LEFT External panels and covers
on page 169
RC1-5192-000CN ARM, FRONT DOOR, LEFT External panels and covers
on page 169
RC1-5194-000CN SHAFT, FRONT DOOR ARM External panels and covers
on page 169
RC1-5200-000CN COVER, CASSETTE DUST External panels and covers
on page 169
RC1-5204-000CN SHEET, LEFT PANEL, LOWER External panels and covers
on page 169
RC1-5228-000CN COVER, CONTROLLER External panels and covers
on page 169
RC1-5229-000CN LID, CONTROLLER External panels and covers
on page 169
RC1-5249-000CN CAM, LEFT Internal components (2 of 3)
on page 175
RC1-5272-000CN LEVER, LINK External panels and covers
on page 169
RC1-5311-000CN CAM, HINGE, RIGHT Internal components (2 of 3)
on page 175
RC1-5440-000CN ROLLER, PAPER PICK-UP Paper pick-up feeder
assembly (tray 2) on page 181
RC1-5440-000CN ROLLER, PAPER PICK-UP Paper pickup feeder
assembly (Tray 3) on page 183
RC1–5346–000CN PANEL FRONT (TRAY 2 FRONT COVER) External panels and covers
on page 169
RC2-1663-000CN COVER, UPPER, RIGHT Upper cover assembly
on page 171
RC2-1664-000CN COVER, UPPER, LEFT Upper cover assembly
on page 171
RC2-1665-000CN COVER, CABLE Upper cover assembly
on page 171
RC2-1671-000CN TRAY, FACE-UP External panels and covers
on page 169
RC2-1672-000CN COVER, FACE-DOWN External panels and covers
on page 169
RC2-1675-000CN COVER, FACE-UP, REAR External panels and covers
on page 169
RC2-1682-000CN ROLLER, FACE-UP External panels and covers
on page 169
RC2-1687-000CN PLATE, REAR External panels and covers
on page 169
Table 7-20 Numerical parts list (continued)
202 Chapter 7 Parts and diagrams ENWW
