6. Align the print cartridge with the tracks inside the printer, and using the handles, insert the print
cartridge until it is firmly seated.
WARNING! Inserting the print cartridge at an angle (left side or right side ahead of the
other) can cause damage to the E-label-reader guide pin. If the E-label-reader guide pin
is broken, the control panel displays a 10.000x Supply error.
Figure 5-1 E-label-reader guide pin
7. Firmly close the front door.
After a short time, the control panel should display Ready.
NOTE If a cartridge is in the wrong slot or is the wrong type for the printer, the control
panel will display one of the following messages: Incorrect yellow, Incorrect magenta,
Incorrect cyan, or Incorrect black.
8. Installation is complete. Place the used print cartridge in the box in which the new cartridge
arrived. See the enclosed recycling guide for recycling instructions.
9. If you are using a non-HP print cartridge, check the printer control panel for further instructions.
NOTE When replacing or changing a black print cartridge, a cleaning page automatically
prints. This helps prevent speckles on the front or back of printed documents.
68 Chapter 5 Removal and replacement ENWW
