Parallel connection
Establish a parallel connection by connecting the MFP to the computer with a bidirectional parallel cable
(IEEE-1284C compliant) that has a c-connector. The cable can be a maximum of 10 meters (30 feet)
long.
Figure 6-1 Parallel port connection
1 C-connector
2 Parallel port
NOTE To use the enhanced capabilities of the bidirectional parallel interface, ensure that the
most recent printer driver is installed.
Factory settings support automatic switching between the parallel port and one or more network
connections on the MFP.
78 Chapter 6 Connectivity ENWW
