Base model back view
7 Power connector
8 Rear door for jam access
9 Hi-Speed USB 2.0 port
Fax/memory-card model front view
1 Tray 1
2 Print-cartridge door latch
3 Top (face-down) output bin
4 Control panel
5 Automatic document feeder (ADF) input tray
6 Automatic document feeder (ADF) output bin
7 Memory card slots
6 Chapter 1 Product basics ENWW
