3. Remove the DIMM access door.
4. To replace an installed DIMM, spread the latches apart on each side of the DIMM slot, lift the DIMM
up at an angle, and then pull it out.
5. Remove the new DIMM from the antistatic package, and then find the alignment notch on the
bottom edge of the DIMM.
ENWW Memory and font DIMMs 51
