HP Compaq 15 User Manual

2 External component identification
Display
Component Description
(1) WLAN antennas (1 or 2)* (select models only) Send and receive wireless signals to communicate with wireless local
area networks (WLANs).
(2) WWAN antennas (1 or 2)* (select models only) Send and receive wireless signals to communicate with wireless wide
area networks (WWAN).
(3) Webcam light On: The webcam is in use.
(4) Webcam Records video and captures photographs. Some models allow you to
video conference and chat online using streaming video.
To use the webcam in Windows 8, from the Start screen, type
camera, and then select Camera from the list of applications.
(5) Internal microphone Records sound.
(6) Internal display switch Turns off the display and initiates Sleep if the display is closed while
the power is on.
NOTE: The internal display switch is not visible from the outside of
the computer.
*The antennas are not visible from the outside of the computer. For optimal transmission, keep the areas immediately around the
antennas free from obstructions. For wireless regulatory notices, see the section of the Regulatory, Safety, and Environmental Notices
that applies to your country or region. To access this guide in Windows 8, from the Start screen, type support, and then select the
HP Support Assistant app.
Display 5

HP Compaq 15 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Grey
Country of origin	China
Processor cache	1 MB
Processor cores	2
Processor family	AMD E
Processor frequency	1.35 GHz
Processor cache type	L2
Processor manufacturer	AMD
Motherboard chipset	-
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 8 GB
HDD speed	5400 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	1000 GB
Number of HDDs installed	1
Display surface	Gloss
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Discrete graphics card model	Not available
On-board graphics card model	AMD Radeon R2
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
CardBus PCMCIA slots quantity	0
Operating system installed	Windows 8.1
Operating system architecture	64-bit
Battery capacity	41 Wh
Battery life (max)	- h
Number of battery cells	4
Cable lock slot type	Kensington
Sustainability certificates	EPEAT Silver, ENERGY STAR

Weight and Dimensions

Depth	260 mm
Width	378 mm
Height	25 mm
Weight	2230 g
