Hard drive
NOTE: The hard drive spare part kit does not include the hard drive bracket.
Description Spare part number
1-GB, 5400-rpm, 2.5-in 676521-001
750-GB, 5400-rpm, 2.5-in 644351-001
500-GB, 5400-rpm, 2.5-in 669299-001
320-GB, 5400-rpm, 2.5-in 634953-001
Hard drive bracket 749648-001
Before removing the hard drive, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 33).
5. Remove the keyboard (see
Keyboard on page 39).
6. Remove the top cover (see
Top cover on page 42).
To remove the hard drive:
1. Remove the two Phillips PM2.5×5.0 screws (1) that secure the hard drive to the computer.
2. Slide the hard drive to disengage it from the connector (2).
48 Chapter 4 Removal and replacement procedures

HP Compaq 15 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Grey
Country of origin	China
Processor cache	1 MB
Processor cores	2
Processor family	AMD E
Processor frequency	1.35 GHz
Processor cache type	L2
Processor manufacturer	AMD
Motherboard chipset	-
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 8 GB
HDD speed	5400 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	1000 GB
Number of HDDs installed	1
Display surface	Gloss
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Discrete graphics card model	Not available
On-board graphics card model	AMD Radeon R2
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
CardBus PCMCIA slots quantity	0
Operating system installed	Windows 8.1
Operating system architecture	64-bit
Battery capacity	41 Wh
Battery life (max)	- h
Number of battery cells	4
Cable lock slot type	Kensington
Sustainability certificates	EPEAT Silver, ENERGY STAR

Weight and Dimensions

Depth	260 mm
Width	378 mm
Height	25 mm
Weight	2230 g
