HP Compaq 2230s User Manual

Illustrated parts catalog 3–14
493189-001 Display cables (includes display, microphone, and antenna cables)
493190-001 Display Miscellaneous Kit (includes rubber feet, screw covers, and hinge cover)
493191-001 Display nameplate
493192-001 Display hinges
493193-001 Display inverter
493194-001 Memory module, 1024-MB
493195-001 Memory module, 2048-MB
493196-001 Hard drive, 120-GB, 5400-rpm
493197-001 Hard drive, 160-GB, 5400-rpm
493198-001 Hard drive, 250-GB, 5400-rpm
493199-001 Hard drive, 320-GB, 5400-rpm
493200-001 DVD/CD-RW Combo Drive (includes drive bezel and bracket)
493201-001 DVD-ROM Drive (includes drive bezel and bracket)
493202-001 Battery, 4-cell, 37-Wh
493269-001 Fan
493270-001 Thermal module (includes heat sink and thermal material)
493271-001 Base enclosure (includes rubber feet)
493272-001 Audio board
493273-001 Speaker assembly
493274-001 Plastics Kit (see “Plastics Kit” on page 3-9 for more Plastics Kit spare part information)
493275-001 Cable Kit (see “Cable Kit” on page 3-8 for more Cable Kit information)
493276-001 Rubber Kit (contains 5 computer feet)
493277-001 Screw Kit
493278-001 Top cover (includes TouchPad and cable, LED board and cable, and switch cover)
493960-001 Keyboard for use in the United States
493960-031 Keyboard for use in the United Kingdom
493960-041 Keyboard for use in Germany
493960-051 Keyboard for use in France
493960-061 Keyboard for use in Italy
493960-071 Keyboard for use in Spain
493960-081 Keyboard for use in Denmark
493960-091 Keyboard for use in Norway
493960-121 Keyboard for use in Canada
493960-131 Keyboard for use in Portugal
493960-141 Keyboard for use in Turkey
493960-161 Keyboard for use in Latin America
493960-171 Keyboard for use in Saudi Arabia
493960-211 Keyboard for use in Hungary
(Continued)
Spare part number Description

HP Compaq 2230s Specifications

General

Processor model	-
Processor family	Intel® Celeron® M
Processor manufacturer	Intel
HDD speed	5400 RPM
HDD interface	SATA
Card reader integrated	No
Total storage capacity	120 GB
Display surface	Gloss
Display diagonal	12.1 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Internal memory	4 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Type	PC
Modem speed	56 Kbit/s
Internal modem	Yes
Wireless technology	802.11a/b/g/n draft 2.0
Bluetooth version	2.0+EDR
Networking features	Marvell Ethernet (10/100/1000 NIC)
Operating system installed	Windows Vista Business
Number of battery cells	4
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	3
AC adapter power	65 W
Battery performance	37 W
Pointing device	Touchpad + Scroll zone
Country of origin	China

Weight and Dimensions

Depth	294 mm
Height	226 mm
Weight	1850 g
Height (front)	28 mm
