HP Compaq 2230s User Manual

Illustrated parts catalog 3–15
493960-221 Keyboard for use in the Czech Republic
493960-231 Keyboard for use in Slovakia
493960-251 Keyboard for use in Russia
493960-281 Keyboard for use in Thailand
493960-291 Keyboard for use in Japan
493960-A41 Keyboard for use in Belgium
493960-AB1 Keyboard for use in Taiwan
493960-AD1 Keyboard for use in South Korea
493960-B31 Keyboard for international use
493960-B71 Keyboard for use in Sweden and Finland
493960-BA1 Keyboard for use in Slovenia
493960-BB1 Keyboard for use in Israel
493960-BG1 Keyboard for use in Switzerland
493960-DD1 Keyboard for use in Iceland
493960-DJ1 Keyboard for use in Greece
493961-001 DVD±RW SuperMulti Double-Layer Drive with LightScribe (includes drive bezel and bracket)
495015-001 Display bezel
495016-001 Display hinge covers
496458-001 Intel Core2 Duo processor (6-MB L2 cache, 1066-MHz FSB), P9500 2.53-GHz (includes
replacement thermal material)
497536-001 Blu-ray ROM DVD±RW SuperMulti DL Drive (includes drive bezel and bracket)
500770-001 Intel Core Duo processor (2-MB L2 cache, 800-MHz FSB), P5670 1.8-GHz (includes replacement
thermal material)
500771-001 Intel Core Duo processor (2-MB L2 cache, 800-MHz FSB), P5870 2.0-GHz (includes replacement
thermal material)
501932-001 12.1-inch, WXGA display assembly with integrated webcam
501933-001 12.1-inch, WXGA BrightView display assembly with integrated webcam
501934-001 Display bezel with webcam
501935-001 Battery, 8-cell, 73-Wh
504446-001 System board, GL40 (includes RTC battery and replacement thermal material)
507966-001 Intel Core2 Duo processor (3-MB L2 cache, 1066-MHz FSB), P7370 2.0-GHz (includes replacement
thermal material)
509058-001 Intel Celeron-T processor (1-MB L2 cache, 667-MHz FSB), T1600 1.66-GHz (includes replacement
thermal material)
509059-001 Intel Celeron-T processor (1-MB L2 cache, 667-MHz FSB), T1700 1.83-GHz (includes replacement
thermal material)
509060-001 Intel Core Duo processor (1-MB L2 cache, 667-MHz FSB), T3200 2.0-GHz (includes replacement
thermal material)
509061-001 Intel Core Duo processor (1-MB L2 cache, 667-MHz FSB), T3400 2.16-GHz (includes replacement
thermal material)
512585-001 Intel Core2 Duo processor (3-MB L2 cache, 1066-MHz FSB), P8700 2.53-GHz (includes
replacement thermal material)
513695-001 Hard drive, 160-GB, 7200-rpm
Spare part number Description

HP Compaq 2230s Specifications

General

Processor model	-
Processor family	Intel® Celeron® M
Processor manufacturer	Intel
HDD speed	5400 RPM
HDD interface	SATA
Card reader integrated	No
Total storage capacity	120 GB
Display surface	Gloss
Display diagonal	12.1 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Internal memory	4 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Type	PC
Modem speed	56 Kbit/s
Internal modem	Yes
Wireless technology	802.11a/b/g/n draft 2.0
Bluetooth version	2.0+EDR
Networking features	Marvell Ethernet (10/100/1000 NIC)
Operating system installed	Windows Vista Business
Number of battery cells	4
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	3
AC adapter power	65 W
Battery performance	37 W
Pointing device	Touchpad + Scroll zone
Country of origin	China

Weight and Dimensions

Depth	294 mm
Height	226 mm
Weight	1850 g
Height (front)	28 mm
