HP Compaq 6005 Pro Specifications

Serviceability Features of System
Serviceability Features of SystemServiceability Features of System
Serviceability Features of System
Dual Color Power LED on Front of Computer (Indicates Normal Operations and Fault Conditions)
Diagnostic LED Explanation Table Number of 1-second red LED blinks followed by 2-second pause, then repeats:
2-processor thermal protection activated
3-processor not installed
4-power supply failure
5-memory error
6-video error
7-PCA failure (ROM detected failure prior to video)
8-invalid ROM, bootblock recover mode
System/Emergency ROM Flash ROM CMOS Battery Holder for easy
Replacement
Flash Recovery with Video 5 Aux Power LED on System PCA Processor ZIF Socket for easy
Upgrade
Over-Temp Warning on Screen
(Requires IM Agents)
Clear Password Jumper DIMM Connectors for easy Upgrade
Restore CD Clear CMOS Switch NIC LEDs (integrated) (Green &
Amber)
Serviceability Features of Chassis
Serviceability Features of ChassisServiceability Features of Chassis
Serviceability Features of Chassis
Dual Color Power and HD LED - To
Indicate Normal Operations and
Fault Conditions
Color coordinated cables and
connectors
Tool-less Hood Removal
(thumbscrews for Microtower, spring-
loaded latch for Small Form Factor)
Front power switch System memory can be upgraded on
Microtower without removing any
internal components
Tool-less Hard Drive, CD & Diskette
Removal
Additional Features
Additional FeaturesAdditional Features
Additional Features Description
DescriptionDescription
Description
Towerable Small Form Factor can be oriented as a tower (in addition to desktop orientation)
Drive Self Tests (DPS) Drive Protection System
A diagnostic hard drive self test. It scans critical physical components and every
sector of the hard drive for physical faults and then reports any faults to the user.
Running independently of the operating system, it can be accessed through a
Windows-based diagnostics utility or through the computer's setup procedure. It
produces an evaluation on whether the hard drive is the source of the problem
and needs to be replaced.
The system expands on the Self-Monitoring, Analysis, and Reporting Technology
(SMART), a continuously running systems diagnostic that alerts the user to certain
types of failures.
DPS Access through F10 Setup during Boot
SMART IV Technology *
(Self-Monitoring, Analysis and Reporting
Technology)
Allows hard drives to monitor their own health and to raise flags if imminent failures
were predicted
Predicts failures before they occur. Tracks fault prediction and failure indication
parameters such as re-allocated sector count, spin retry count, calibration retry
count
By avoiding actual hard drive failures, SMART hard drives act as "insurance"
against unplanned user downtime and potential data loss from hard drive failure
DASH 1.1 support (Desktop and Mobile
Architecture for System Hardware)
A standards initiative for representing out-of-band management capability for computer
systems. It is a secure, web-services based successor to ASF.
QuickSpecs
HP Compaq 6005 Pro Business PC
HP Compaq 6005 Pro Business PCHP Compaq 6005 Pro Business PC
HP Compaq 6005 Pro Business PC
Technical Specifications
DA - 13412 North America — Version 7 — November 4, 2009 Page 19

HP Compaq 6005 Pro Specifications

General

Processor cache	2 MB
Processor cores	2
Processor model	B26
Processor family	AMD Athlon II X2
Processor frequency	3.2 GHz
Processor cache type	L2
Processor manufacturer	AMD
Number of processors installed	1
Operating system installed	Windows 7 Professional
Compatible operating systems	FreeDOS
Operating system architecture	32-bit
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	320 GB
Audio system	HD
Product type	PC
Motherboard chipset	AMD 785G
Memory slots	4x DIMM
Internal memory	2 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 2 GB
Networking features	Gigabit Ethernet
Floppy drive installed	No
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Discrete graphics card model	AMD Radeon HD 4200
Display diagonal	24 \
Display brightness	300 cd/m²
Display resolution	1920 x 1200 pixels
Native aspect ratio	16:10
Viewing angle, horizontal	160 °
USB 2.0 ports quantity	6
Parallel ports quantity	-
Firewire (IEEE 1394) ports	0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Power supply input voltage	110 - 240 V
Power supply input frequency	50 - 60 Hz

Weight and Dimensions

Depth	430 mm
Width	176 mm
Height	377 mm
Weight	9300 g
