HP Compaq 6005 Pro Specifications

Compliance standards
Compliance standardsCompliance standards
Compliance standards EMC Emissions :
a) FCC Part 15, Subpart B - Unintentional Radiators, Class B Computing
Devices for Home & Office Use
b) CISPR22: 1997/EN 55022:1998 - Class B - Limits and methods of
measurement of radio disturbance characteristics of Information
Technology Equipment
c) Canadian Standard ICES-003 is equivalent to CISPR22
d) Taiwanese Standard BSMI
e) Japanese VCCI
f) Australian C-Tick
g) Korean (KCC)
EMC Immunity :
CISPR 24:1997/EN 55024:1998 - Information Technology Equipment -
Immunity Characteristics - Limits and Methods of Measurement.
ATI Radeon HD 4550 DH PCIe x16 Graphics Card display resolutions and refresh rates
ATI Radeon HD 4550 DH PCIe x16 Graphics Card display resolutions and refresh ratesATI Radeon HD 4550 DH PCIe x16 Graphics Card display resolutions and refresh rates
ATI Radeon HD 4550 DH PCIe x16 Graphics Card display resolutions and refresh rates
NOTE:
NOTE:NOTE:
NOTE: Other resolutions may be available but are not recommended as the may not have been tested and qualified by HP.
Maximum Refresh Rate
Maximum Refresh RateMaximum Refresh Rate
Maximum Refresh Rate (Hz)
Resolution
ResolutionResolution
Resolution Analog Connection
Analog ConnectionAnalog Connection
Analog Connection Digital Connection
Digital ConnectionDigital Connection
Digital Connection
640x480 85 60
800x600 85 60
1024x768 85 60
1280x720 85 60
1280x1024 85 60
1440x900 75 60
1600x1200 85 60
1680x1050 75 60
1920x1080 85 60-R
1920x1200 85 60-R
1920x1440 85 N/A
2048x1536 75 N/A
2560x1600 N/A N/A
NOTE:
NOTE:NOTE:
NOTE: 60-R denotes reduced blanking timings are used on single-link DVI connections and may be used with other digital
connections.
NVIDIA Quadro NVS 290
NVIDIA Quadro NVS 290NVIDIA Quadro NVS 290
NVIDIA Quadro NVS 290
PCIe x1 Graphics Card
PCIe x1 Graphics CardPCIe x1 Graphics Card
PCIe x1 Graphics Card
Bus type
Bus typeBus type
Bus type PCIe x1
Low profile, both ATX and low profile brackets included
Graphics Controller
Graphics ControllerGraphics Controller
Graphics Controller Integrated Quadro 290 2D graphics processor unit (GPU)
Memory
MemoryMemory
Memory 256 MB DDR2
Connector
ConnectorConnector
Connector Single high-density DMS-59 Flex Connector
Dimensions
DimensionsDimensions
Dimensions Low-profile, 2.586 x 6.6 in (6.57 x 16.76 cm)
Multi-monitor support
Multi-monitor supportMulti-monitor support
Multi-monitor support Dual analog or digital (Single Link DVI) monitors
(DVI support requires optional DVI cable kit DL139A)
RAMDAC
RAMDACRAMDAC
RAMDAC Dual 350 MHz (integrated)
Maximum pixel clock
Maximum pixel clockMaximum pixel clock
Maximum pixel clock 350 MHz
Overlay planes
Overlay planesOverlay planes
Overlay planes One 1-bit Video overlay plane
QuickSpecs
HP Compaq 6005 Pro Business PC
HP Compaq 6005 Pro Business PCHP Compaq 6005 Pro Business PC
HP Compaq 6005 Pro Business PC
Technical Specifications - Graphics
DA - 13412 North America — Version 7 — November 4, 2009 Page 29

HP Compaq 6005 Pro Specifications

General

Processor cache	2 MB
Processor cores	2
Processor model	B26
Processor family	AMD Athlon II X2
Processor frequency	3.2 GHz
Processor cache type	L2
Processor manufacturer	AMD
Number of processors installed	1
Operating system installed	Windows 7 Professional
Compatible operating systems	FreeDOS
Operating system architecture	32-bit
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	320 GB
Audio system	HD
Product type	PC
Motherboard chipset	AMD 785G
Memory slots	4x DIMM
Internal memory	2 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 2 GB
Networking features	Gigabit Ethernet
Floppy drive installed	No
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Discrete graphics card model	AMD Radeon HD 4200
Display diagonal	24 \
Display brightness	300 cd/m²
Display resolution	1920 x 1200 pixels
Native aspect ratio	16:10
Viewing angle, horizontal	160 °
USB 2.0 ports quantity	6
Parallel ports quantity	-
Firewire (IEEE 1394) ports	0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Power supply input voltage	110 - 240 V
Power supply input frequency	50 - 60 Hz

Weight and Dimensions

Depth	430 mm
Width	176 mm
Height	377 mm
Weight	9300 g
