HP Compaq 6005 Pro Specification

High Definition Audio
Type Integrated
HD Stereo Codec Realtek 2-channel ALC261 codec
Audio I/O Ports Front microphone-In (150-K ohm Input Impedance)
Rear Line-In/Microphone input (150-K ohm Input Impedance, function is configurable by audio
driver)
Rear Line-Out * (190 ohms Output Impedance, expects at least a 10-K ohm load)
Front Headphone-Out (0.5 Ohm Output Impedance, expects at least a 32 ohm load)
Front Microphone/Headphone jack is re-task able to provide Microphone input, line-in or Headphone
output to support connecting two headphones to the front of the system. When configured as a
second front headphone output, both front headphone outputs are always driven with the same
signal.
All ports are 3.5mm in diameter
Internal Speaker Amplifier For the internal speaker only. External speakers must be powered externally. Rear Line-in audio port
is re-taskable as either Line-in or Microphone-In.
Multi-streaming Capable Multi-streaming can be enabled in the Realtek control panel to allow independent audio streams to
be sent to/from the front and rear jacks.
Sampling 8 kHz - 192 kHz
Wavetable Syntheses
(software)
Yes - Uses OS soft wavetable
Analog Audio Yes
# of Channels on Line-Out
( mono/stereo)
Stereo (Left & Right channels)
Internal Audio Speaker Power
Rating
1.5 W
Internal Speaker Yes
External Speaker Jack
(Line-Out)
Yes
QuickSpecs
HP Compaq 6005 Pro Series
Technical Specifications - Audio
DA - 13412 North America — Version 35 — August 14, 2013 Page 22

HP Compaq 6005 Pro Specifications

General

Processor cache	2 MB
Processor cores	2
Processor model	B26
Processor family	AMD Athlon II X2
Processor frequency	3.2 GHz
Processor cache type	L2
Processor manufacturer	AMD
Number of processors installed	1
Operating system installed	Windows 7 Professional
Compatible operating systems	FreeDOS
Operating system architecture	32-bit
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	320 GB
Audio system	HD
Product type	PC
Motherboard chipset	AMD 785G
Memory slots	4x DIMM
Internal memory	2 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 2 GB
Networking features	Gigabit Ethernet
Floppy drive installed	No
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Discrete graphics card model	AMD Radeon HD 4200
Display diagonal	24 \
Display brightness	300 cd/m²
Display resolution	1920 x 1200 pixels
Native aspect ratio	16:10
Viewing angle, horizontal	160 °
USB 2.0 ports quantity	6
Parallel ports quantity	-
Firewire (IEEE 1394) ports	0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Power supply input voltage	110 - 240 V
Power supply input frequency	50 - 60 Hz

Weight and Dimensions

Depth	430 mm
Width	176 mm
Height	377 mm
Weight	9300 g
